Polycom SoundPoint IP 670 User Manual

User Guide for the SoundPoint IP 670 Desktop Phone
1 - 16
The USB port is on the back of your SoundPoint IP 670 as shown below:
When you plug in the USB device, the USB device is supported and the
message “USB device attached.” appears.
When you remove the USB device, the message “USB device removed.”
appears.
Cleaning the LCD Glass
Clean the glass with a clean lint-free cloth. Fingerprints tend to show up more
obviously on the color LCD.
Note
Wait until the “USB device removed.” message disappears before plugging in
another USB device. If you plug in a new USB device before the message
disappears, it will not be recognized.
Polycom recommends that you do not remove the USB device while recording. The
file being recorded at that time will be incomplete and cannot be played back later.
There is a small probability that the USB device itself may be damaged by this
action.

Polycom SoundPoint IP 670 Specifications

General

Voice codecs	G.711, G.722, G.729
Noise reduction	Yes
Microphone frequency	150 - 7000 Hz
Caller ID	-
Phonebook capacity	- entries
Security algorithms	HTTPS
Supported network protocols	SNTP/FTP/TFTP/HTTP
Display resolution	320 x 160 pixels
Ethernet LAN (RJ-45) ports	2
Product type	IP Phone
Product color	Gray
Dimensions (WxDxH)	265 x 190 x 150 mm
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Certification	FCC, RoHS, CE
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	1260 g
