Polycom SoundPoint IP 670 User Manual

Using the Basic Features of Your Phone
3 - 21
To disable call forwarding:
1. From the idle display, press the Forward soft key.
2. .(Optional.) If multiple lines are configured on your phone, select the line
to forward from the list using and .
3. Using and , select the forwarding type you want to change and
then press the Select soft key.
4. Press the Disable soft key.
The idle display returns and the regular icon appears as the line indicator.
Dynamic Forwarding
To forward an incoming call to another party:
1. When the phone rings, press the Forward soft key.
2. Enter a number to forward the incoming call to.
3. Press the Enable soft key.
The incoming call is forwarded to the other party. If call forwarding is
disabled, all future calls will not be forwarded and forwarding will remain
disabled.
Enabling Do Not Disturb
To prevent the phone ringing (from incoming calls), you can select Do Not
Disturb.
Note
This feature is local to the phone, and may be overridden by call server settings.
For more information, contact your system administrator.

Polycom SoundPoint IP 670 Specifications

General

Voice codecs	G.711, G.722, G.729
Noise reduction	Yes
Microphone frequency	150 - 7000 Hz
Caller ID	-
Phonebook capacity	- entries
Security algorithms	HTTPS
Supported network protocols	SNTP/FTP/TFTP/HTTP
Display resolution	320 x 160 pixels
Ethernet LAN (RJ-45) ports	2
Product type	IP Phone
Product color	Gray
Dimensions (WxDxH)	265 x 190 x 150 mm
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Certification	FCC, RoHS, CE
Harmonized System (HS) code	85171800

Weight and Dimensions

Weight	1260 g
