Using the SoundPoint IP Color Expansion Module
5 - 5
Adjusting the Display Contrast
To adjust the display contrast on a SoundPoint IP ColorExpansion Module,
refer to Changing the Display Contrast on page 2-3.
Adjusting the Backlight
To adjust the backlight on a SoundPoint IP Color Expansion Module, refer to
Changing the Backlight Intensity on page 2-4.
Placing Calls
When you connect a SoundPoint IP Color Expansion Module to your phone,
you can place a call using one of the Line Keys.
3 Line Indicators Individual multi-color LEDs display
the dynamic call state and remote
user status (busy lamp field [BLF] and
presence). The mapping is:
Solid green—An active call is in
progress.
Fast flashing green—There is an
incoming (ringing) call.
Flashing green—Another party has
put you on hold.
Flashing red—The call is on hold.
Solid red—The line is busy remotely
(shared lines).
4 Graphic Display Shows information about lines or
speed dials.
5 Infrared Lens Facilitates communications to the
host phone and other Expansion
Modules.
Item Description
Note
Once you have saved your new display contrast setting, there may be some delay
before the Expansion Module display returns to the selected background.
