1-10
1 Safety Information
1.5.5 Warning Labels on the Instrument
Warning labels
The lamp warning label is shown in the following figure. For countries in the
European Union (EU), the warning label is affixed in the language spoken in
the customer's country.
Figure 1.4: Lamp warning label
Position of lamp
warning label
The position of the lamp warning label on the sensor head is shown in the
following figure.
Figure 1.5: Position of the lamp warning label [1] as well as the beam exit aperture with the
beam direction [2]
!"#$
!%&'
(!#)
* %+
,
(-./
0!!
1#'
%#23#
'/!#%
*+
