6-6
6 Technical Specifications
Interference Objectives (for Topography Measurements)
6.3 MSA-F-620 Front-End
6.3.1 General Data
Mains Connection
Ambient Conditions
Housing
Article name
Objective
manufacturer
Type Magnification
Nominal objective
working distance
Field of view
x [mm] [mm x mm]
A-IOB-02X5-B Nikon Michelson 2.5 10.3 4.1 x 2.8
A-IOB-005X-B Nikon Michelson 5 9.3 2.0 x 1.4
A-IOB-010X-B Nikon Mirau 10 7.4 1.0 x 0.70
A-IOB-020X-B Nikon Mirau 20 4.7 0.51 x 0.35
A-IOB-050X-B Nikon Mirau 50 3.4 0.20 x 0.14
A-IOB-100X-B Nikon Mirau 100 2 0.10 x 0.070
A-IOB-004X-LD-B Polytec Michelson 4 26.6 2.5 x 1.8
Mains voltage: 100… 240 VAC ±10%, 50/60 Hz
Power consumption (including
sensor head): max. 100 VA
Fuses: 3.15 A/slow-blow
Protection class: 1 (according to EN 61140)
Operating temperature: +5 …+40 °C (41…104 °F)
Storage temperature: –10…+65 °C (14…149 °F)
Air humidity: max. 80%, non-condensing
Protection rating: IP20 (according to EN 60529)
Dimensions (w x h x d): Without angle brackets:
450 mm x 150 mm x 380 mm (19", 84 HP/3 U)
With angle brackets:
485 mm x 150 mm x 380 mm (19", 84 HP/3 U)
Weight: 9 kg
