Polytec MSA-600 User Manual

3-1
3 First Steps
3 First Steps
3.1 Unpacking and Inspection
ATTENTION!
Damage to the optics caused by vibration!
The optical components are highly sensitive. Shocks or vibrations can cause
damage to the components or impair its function.
» Protect the unpacked device from being shaken.
INFORMATION
Components marked with an (*) are described in separate documentations.
Pay attention to these documentations, too.
Unpacking The scope of supply includes the following components:
• 1 MSA-I-620 Sensor Head
• 1 MSA-F-620 Front-End
• 1 MSA-E-600 Controller
• 1 MSA-W-620 Data Management System
• 1 A-CAB-BAS System Cabinet
• 1 A-MOB-020X 20x Microscope Objective
• 1 UHF-A-SAW SAW Filter with assembly kit
• 1 MSA-A-MEMS Resonator
• 1 ZFDC-20-5 Directional Coupler
• 1 Stage micrometer for objective calibration (> 5x magnification)
• 2 Mains cable
• 1 System cable
• 1 Scanner cable
• 2 Network cables (1x blue / 1x yellow)
• 1 Generator cable
• 1 Acquisition cable
• 1 BC cable
• 1 Protective earth cable (4 m)
• 2 SMA-SMA cables (1 m)
• 1 SMA-SMA cable (2 m)
• 1 BNC-SMA adapter
• 1 Attenuator 20 dB
• 1 Torque wrench 45 Ncm for SMA connections
