4.1 Telemetry
This can be used to display all the sensors connected to the P²BUS, and show the data they generate. This information also
includes the receiver and transmitter data.
Technical information:
The PowerBox CORE telemetry system and the P²-BUS are designed in such a way that each sensor supplies its own informa-
tion, including sensor name, unit, number of sensor values, decimal point, priority and other data. A new sensor designed for use
with the P²-BUS can be connected to the system at any time without updating the transmitter. The advantage of the system is
that all the text information relating to the sensor values is collected only when the system is switched on, i.e., when the system is
booting.
Once the system is running, only the pure sensor values are transferred; this permits very fast data transmission with maximum
flexibility, and ensures a thoroughly user-friendly system.
If you have selected the Telemetry widget type, this display appears, and the following options become available:
4.1.1. Size
With these three buttons you can adjust the size of the widgets:
Small, Medium and Large.
4.1.2. Delete Widget
You can delete the widget with this button.
4.1.3. Rescan Sensors
You will need this function if you connect new sensors when the system is already running. The process gathers all sensor infor-
mation on the P²-BUS. Basically, all sensor information is automatically collected when the system is switched on.
4.1.4. + Button
At this point you can select sensor values using the + button. Each widget can display multiple sensor values, even from
separate sensors; the values then alternate in the widget’s display. This is accomplished by selecting one or more sensor values
which you want to appear in your widget, and pressing OK to confirm.
