Powtran PI500 series User Manual

6
第
十
章
Chapter 2
Chapter 2 Standard specifications
2-1.Technical specifications
Model
Rated output
power(kW)
Rated input
current(A)
Rated output
current(A)
Adaptive
motor(kW)
PI500-7R5G3/PI500-011F3
7.5/11
20.5/26
17/25
7.5/11
PI500-011G3/PI500-015F3
11/15
26/35
25/32
11/15
PI500-015G3/PI500-018F3
15/18.5
35/38.5
32/37
15/18.5
PI500-018G3/PI500-022F3
18.5/22
38.5/46.5
37/45
18.5/22
PI500-022G3/PI500-030F3
22/30
46.5/62
45/60
22/30
PI500-030G3/PI500-037F3
30/37
62/76
60/75
30/37
PI500-037G3/PI500-045F3
37/45
76/91
75/90
37/45
PI500-045G3/PI500-055F3
45/55
91/112
90/110
45/55
PI500-055G3/PI500-075F3
55/75
112/157
110/150
55/75
PI500-075G3
75
157
150
75
PI500-093F3
93
180
176
93
PI500-093G3/PI500-110F3
93/110
180/214
176/210
93/110
PI500-110G3/PI500-132F3
110/132
214/256
210/253
110/132
PI500-132G3/PI500-160F3
132/160
256/307
253/304
132/160
PI500-160G3/PI500-187F3
160/187
307/345
304/340
160/187
PI500-187G3/PI500-200F3
187/200
345/385
340/380
187/200
PI500-200G3/PI500-220F3
200/220
385/430
380/426
200/220
PI500-220G3
220
430
426
220
PI500-250F3
250
468
465
250
PI500-250G3/PI500-280F3
250/280
468/525
465/520
250/280
PI500-280G3/PI500-315F3
280/315
525/590
520/585
280/315
PI500-315G3/PI500-355F3
315/355
590/665
585/650
315/355
PI500-355G3/PI500-400F3
355/400
665/785
650/725
355/400
PI500-400G3
400
785
725
400
PI500-450F3
450
883
820
450
PI500-450G3/PI500-500F3
450/500
883/920
820/860
450/500
PI500-500G3/PI500-560F3
500/560
920/1010
860/950
500/560
PI500-560G3/PI500-630F3
560/630
1010/1160
950/1100
560/630
PI500-630G3/PI500-700F3
630/700
1160/1310
1100/1250
630/700
2-2.Standard specifications
Items
Specifications
Power Input
Rated voltage
AC 3PH 380V(-15%)～440V(+10%)
Input frequency
50Hz/60Hz
Allowing
fluctuations
Voltage continued
volatility：±10%
Less than 3% of voltage unbalance
rate 3%；
Input frequency
fluctuation：±5%；
Distortion satisfy IEC61800-2
standard
Control
system
Control system
High performance vector control inverter based on DSP
Control method
V/F control, vector control W/O PG, vector control W/ PG
Automatic torque
boost function
Realize low frequency (1Hz) and large output torque control under
the V/F control mode.
Acceleration/decel
eration control
Straight or S-curve mode. Four times available and time range is
0.0 to 6500.0s.
