Chapter 5 Function parameter
100
Chapter 5
Motor temperature sensor signal, need to connect to the panel S1, S2, GND terminal.
F8.34
motor over heat protection value
0~200
110
F8.35
Motor overheating forecasting warning threshold
0~200
90
When the motor temperature more than motor overheating protection valve value F8.34,
frequency converter fault alarm, and according to the selected fault protection action way.
When the motor temperature exceeds motor overheating if forecasting warning threshold F8.35 ,
inverter multifunction DO early warning ON signal output motor overheating. The motor
temperature in d0.41 display.
5-2-11.Communication parameter: F9.00-F9.07
Code
Parameter name
Setting range
Factory
setting
Change
limits
F9.00
Baud rate
Units digit
MODBUS
6005
300BPS
0
600BPS
1
1200BPS
2
2400BPS
3
4800BPS
4
9600BPS
5
19200BPS
6
38400BPS
7
57600BPS
8
115200BPS
9
Tens digit
Profibus-DP
115200BPS
0
208300BPS
1
256000BPS
2
512000BPS
3
Hundreds digit
Reserved
Thousands digit
CAN bus baudrate
20
0
50
1
100
2
125
3
250
4
500
5
1M
6
F9.01
Data format
No parity (8-N-2)
0
0
Even parity (8-E-1)
1
Odd parity (8-O-1)
2
No parity (8-N-1)
3
F9.02
This unit address
1~2500 for broadcast address
1
F9.03
Response delay
0ms-20ms
2ms
F9.04
Communication
timeout time
0.0 (invalid), 0.1s-60.0s
0.0
F9.05
Data transfer
format selection
Units igit
MODBUS
30
Non-standard MODBUS protocol
0
Standard MODBUS protocol
1
Tens digit
Profibus
PPO1 format
0
PPO2 format
1
