Powtran PI500 series User Manual

Chapter 5 Function parameter
119
Chapter 5
display
properties
Display
1
Tens digit
E group display selection
Not display
0
Display
1
Hundreds digit
b group display selection
Not display
0
Display
1
Thousands digit
y1 group display selection
Not display
0
Display
1
Ten thousands digit
L group display selection
Not display
0
Display
1
y0.03
User
Parameters
display
Units digit:Reserved
Tens digit：User‟s change parameter display selection
0：Not display；1：Display
00
☆
y0.04
Function code
modification
properties
Modifiable
0
0
☆
Not modifiable
1
User can set whether function code parameter can be modified or not, so as to prevent the risk
that function parameters are altered unexpectedly.
If the function code is set to 0, all function code can be modified; while it is set to 1, all
function code can only be viewed, can not be modified.
5-2-21.Fault query:y1.00-y1.30
Code
Parameter name
Setting range
Factory
setting
Change
limits
y1.00
Type of the first fault
0 to 51
-
●
y1.01
Type of the second fault
0 to 51
-
●
y1.02
Type of the third(at last) fault
0 to 51
-
●
Record the type of the last three faults of inverter, 0 for no fault. Please refer to the related
instructions for the possible causes and solutions for each fault code.
Failure type table:
No.
Failure type
No.
Failure type
0
No fault
20
Encoder/PG card abnormal
1
Inverter unit protection
21
Parameter read and write abnormal
2
Acceleration overcurrent
22
Inverter hardware abnormal
3
Deceleration overcurrent
23
Motor short to ground
4
Constant speed overcurrent
24
Reserve
5
Acceleration overvoltage
25
Reserve
6
Deceleration overvoltage
26
Running time arrival
7
Constant speed overvoltage
27
Custom fault 1
8
Control power failure
28
Custom fault 2
9
Undervoltage
29
Power-on time arrival
10
Inverter overload
30
Off load
11
Motor Overload
31
PID feedback loss when running
12
Input phase loss
40
Fast current limiting timeout
