Powtran PI500 series User Manual

Chapter 9 Options
139
Chapter 9
15.
ACL-0800-EISA-E32U
630/750
800
80
2.00%
0.032
225/175/15*25
16.
ACL-0950-EISA-E27U
800
950
89
2.00%
0.027
225/175/15*25
17.
ACL-1200-EISA-E21U
900/1000
1200
100
2.00%
0.021
225/200/15*25
9-3.AC output reactor
When the connection wire from the inverter to the motor is longer (over 20 meters), it is used to
inhibit over-current caused due to the distributed capacitance. Meanwhile, it can also inhibit the radio
interference of the inverter.
9-3-1.AC output reactor
Item
No.
Model
Power
rating
(kW)
Rated
current
(A)
N.W.
(kg)
Voltage
reduction
(V)
Inductance
(mH)
Installation
dimension
a/b/d(mm)
380V voltage series
1
OCL-0005-EISC-E1M4
1.5
5
3.48
1.00%
1.4
91/65/6*11
2
OCL-0007-EISC-E1M0
2.2
7
2.54
1.00%
1
91/65/6*11
3
OCL-0010-ELSC-EM70
4.0
10
2.67
1.00%
0.7
91/65/6*11
4
OCL-0015-ELSC-EM47
5.5
15
3.45
1.00%
0.47
95/61/6*15
5
OCL-0020-ELSC-EM35
7.5
20
3.25
1.00%
0.35
95/616*15
6
OCL-0030-ELSC-EM23
11
30
5.5
1.00%
0.23
95/818.5*20
7
OCL-0040-ELSC-EM18
15
40
5.5
1.00%
0.18
95/81/8.5*20
8
OCL-0050-ELSC-EM14
18.5
50
5.6
1.00%
0.14
95/81/8.5*20
9
OCL-0060-ELSC-EM12
22
60
5.8
1.00%
0.12
120/72/8.5*20
10
OCL-0080-ELSC-E87U
30
80
6.0
1.00%
0.087
120/72/8.5*20
11
OCL-0090-ELSC-E78U
37
90
6.0
1.00%
0.078
120/72/8.5*20
12
OCL-0120-ELSC-FbU
45
120
9.6
1.00%
0.058
120/92/8.5*20
13
OCL-0150-EISH-E47U
55
150
15
1.00%
0.047
182/87/11*18
14
OCL-0200-EISH-E35U
75
200
17.3
1.00%
0.035
182/97/11*18
15
OCL-0250-EISH-E28U
110
250
17.8
1.00%
0.028
182/97/11*18
16
OCL-0290-EISH-E24U
132
290
24.7
1.00%
0.024
214/101/11*18
17
OCL-0330-EISH-E21U
160
330
26
1.00%
0.021
214/106/11*18
18
OCL-0390-EISH-E18U
185
390
26.5
1.00%
0.018
214/106/11*18
19
OCL-0490-EISH-E14U
220
490
36.6
1.00%
0.014
243/113/12*20
20
OCL-0530-EISH-E13U
240
530
36.6
1.00%
0.013
243/113/12*20
21
OCL-0600-EISH-E12U
280
600
43.5
1.00%
0.012
243/128/12*20
22
OCL-0660-EISH-E4F0
300
660
44
1.00%
0.011
243/128/12*20
