Powtran PI500 series User Manual

Chapter 9 Options
142
Chapter 9
7
YX82G6D-80A-S
380
37
80
6.3
310/170/107
280/142.5/Φ8.5*14
8
YX82G6D-100A-S
380
45
100
6.4
310/170/107
280/142.5/Φ8.5*14
9
YX82G6D-120A-S
380
55
120
7.4
310/170/107
280/142.5/Φ8.5*14
10
YX82G7D-150A-S
380
75
150
8.9
352/185/112
325/151/Φ8.5*14
11
YX82G7D-200A-S
380
93
200
-
352/185/112
325/151/Φ8.5*14
12
YX82G8-400A-B
380
200
300
12
380/220/155
228/195/Φ12
9-6.Output filter
Item
No.
Model
Voltage
(V)
Power rating
(kW)
Rated
current
(A)
N.W.
(kg)
dimension
L/W/H(mm)
Installation
dimension
a/b/d(mm)
1
YX82G2-5A-SL
380
0.75~1.5
5
0.5
100/105/40
50/95/Φ4.5*6.5
2
YX82G2-10A-SL
380
2.2~4
10
0.55
185/105/60
50/95/Φ4.5*6.5
3
YX82G5D-20A-SL
380
5.5~7.5
20
1.6
185/105/60
167.8/85/Φ6.5*9.2
4
YX82G5D-36A-SL
380
11~15
36
1.8
185/105/60
167.8/85/Φ6.5*9.2
5
YX82G5D-50A-SL
380
18.5~22
50
1.7
185/105/60
167.8/85/Φ6.5*9.2
6
YX82G6D-65A-SL
380
30
65
6.2
310/170/107
280/142.5/Φ8.5*14
7
YX82G6D-80A-SL
380
37
80
6.2
310/170/107
280/142.5/Φ8.5*14
8
YX82G6D-100A-SL
380
45
100
6.5
310/170/107
280/142.5/Φ8.5*14
9
YX82G6D-120A-SL
380
55
150
6.5
310/170/107
280/142.5/Φ8.5*14
10
YX82G7D-150A-SL
380
75
200
9.2
352/185/112
325/151/Φ8.5*14
11
YX82G7D-200A-SL
380
93
250
-
352/185/112
325/151/Φ8.5*14
12
YX82G8D-300A-BL
380
110
300
11.5
380/220/155
228/195/Φ12
13
YX82G8D-400A-BL
380
200
400
11.6
380/220/155
228/195/Φ12
14
YX82G9D-630A-BL
380
280~315
630
18.5
448/255/162
290/230/Φ12
9-7.Brake unit and brake resistor
15-22kW PI500 frequency inverter is with built-in brake unit, maximum brake torque is 50%.
User should select the brake resistor according to below chart; 30kW and 30kW above unit should use
additional brake unit, brake unit and brake resistor are listed below.
1.380V 18kW~22kW below models (built-in ) braking resistor selection as below:
Frequency inverter
voltage
Capability (kW)
Resistance of braking
resistor(Ω)
Capability of braking
resistor(kW)
380V
7.5 kW
75Ω
780W
11 kW
50Ω
1000W
15 kW
40Ω
1500W
18.5 kW
32Ω
1800W
22 kW
25Ω
2100W
