Chapter 4 Installation and commissioning
16
Chapter 4
Deflector
Cool wind
Hot wind
Diagram 4-2：Heat insulation deflector up and down installation diagram
4-3.Wiring Diagram
Frequency inverter wiring is divided by main circuit and control circuit. Users must properly
connect frequency inverter in accordance with the wiring connection diagram showing below.
