Powtran PI500 series User Manual

Chapter 9 Options
141
Chapter 9
7
DCL-0023-EIDH-E3M6
7.5
23
3.8
3.6
87/70/6*11
8
DCL-0033-EIDH-E2M0
11
33
4.3
2
87/70/6*11
9
DCL-0033-EIDH-E2M0
15
33
4.3
2
87/70/6*11
10
DCL-0040-EIDH-E1M3
18.5
40
4.3
1.3
87/70/6*11
11
DCL-0050-EIDH-E1M1
22
50
5.5
1.08
95/85/8.4*13
12
DCL-0065-EIDH-EM80
30
65
7.2
0.8
111/85/8.4*13
13
DCL-0078-EIDH-EM70
37
78
7.5
0.7
111/85/8.4*13
14
DCL-0095-EIDH-EM54
45
95
7.8
0.54
111/85/8.4*13
15
DCL-0115-EIDH-EM45
55
115
9.2
0.45
125/90/9*18
16
DCL-0160-UIDH-EM36
75
160
10
0.36
100/98/9*18
17
DCL-0180-UIDH-EM33
93
180
20
0.33
100/98/9*18
18
DCL-0250-UIDH-EM26
110
250
23
0.26
176/115/11*18
19
DCL-0250-UIDH-EM26
132
250
23
0.26
176/115/11*18
20
DCL-0340-UIDH-EM17
160
340
23
0.17
176/115/11*18
21
DCL-0460-UIDH-EM09
185
460
28
0.09
191/115/11*18
22
DCL-0460-UIDH-EM09
220
460
28
0.09
191/115/11*18
23
DCL-0650-UIDH-E72U
300
650
33
0.072
206/125/11*18
690V voltage series
1.
DCL-0095-UIDA-E1M0
55
95
-
1.0
100/127/9*18
2.
DCL-0120-UIDA-EM85
75
120
-
0.85
100/142/9*18
3.
DCL-0165-UIDA-EM65
90
165
-
0.65
176/126/11*18
4.
DCL-0210-UIDA-EM47
132
210
-
0.47
176/131/11*18
5.
DCL-0264-UIDA-EM38
160
264
-
0.38
176/151/11*18
9-5.Input filter
Item
No.
Model
Voltag
e (V)
Power
rating
(kW)
Rated
current
(A)
N.W.
(kg)
dimension
L/W/H
(mm)
Installation dimension
a/b/d(mm)
1
YX82G2-5A-S
380
0.75~1.5
5
0.54
100/105/40
50/95/Φ4.5*6.5
2
YX82G2-10A-S
380
2.2~4
10
0.55
100/105/40
50/95/Φ4.5*6.5
3
YX82G5D-20A-S
380
5.5~7.5
16
1.6
185/105/60
167.8/85/Φ6.5*9.2
4
YX82G5D-36A-S
380
11~15
36
1.8
185/105/60
167.8/85/Φ6.5*9.2
5
YX82G5D-50A-S
380
18.5~22
45
1.6
185/105/60
167.8/85/Φ6.5*9.2
6
YX82G6D-65A-S
380
30
65
-
310/170/107
280/142.5/Φ8.5*14
