Chapter 3 Keyboard
14
Chapter 3
b0.04: motor rated
frequency
b0.05: motor rated speed
For asynchronous motors
If the motor can NOT completely disengage its load, please select 1 (asynchronous motor
parameter static auto turning) for b0.27, and then press the RUN key on the keyboard panel.
If the motor can completely disengage its load, please select 2 (asynchronous motor parameter
comprehensive auto turning) for b0.27, and then press the RUN key on the keyboard panel, the
inverter will automatically calculate the motor‟s following parameters:
Motor Selection
Parameters
Motor
b0.06:asynchronous motor stator resistance b0.07:asynchronous motor rotor
resistance
b0.08:asynchronous motor leakage inductance b0.09: asynchronous motor
mutual inductance
b0.10: asynchronous motor no-load current
Complete
motor parameter auto turning
