Powtran PI500A Series User Manual

Chapter 5 Function parameter
36
Chapter 5
91
F1.20
Minimum input for AIC3
-10.00V to F1.22
0.00V
☆
92
F1.21
F1.20corresponding setting
-100.0% to +100.0%
0.0%
☆
93
F1.22
Maximum input for AIC 3
F1.20 to +10.00V
10.00V
☆
94
F1.23
F1.22corresponding setting
-100.0% to +100.0%
100.0%
☆
95
F1.24
AIcurve selection
Units digit: AI1 curve selection
Tens digit: AI2 curve selection
Hundreds digit:panel
potentiometer curve selection
321
☆
96
F1.25
Setting selection for AI input
Units digit: setting selection for
AI1 less than minimum input
0: corresponding to minimum
setting 1: 0.0%
Tens digit: setting selection for
AI2 less than minimum input,
ditto
Hundreds digit: setting selection
for AI3 less than minimum
input(0 to 1,ditto)
000
☆
97
F1.26
HDI Minimum pulse input
0.00kHz to F1.28
0.00kHz
☆
98
F1.27
F1.26 corresponding setting
-100.0% to +100.0%
0.0%
☆
99
F1.28
HDI Maximum input
F1.26 to 100.00kHz
50.00kHz
☆
100
F1.29
F1.28 corresponding setting
-100.0% to +100.0%
100.0%
☆
101
F1.30
DI filter time
0.000s to 1.000s
0.010s
☆
102
F1.31
AI1 filter time
0.00s to 10.00s
0.10s
☆
103
F1.32
AI2 filter time
0.00s to 10.00s
0.10s
☆
104
F1.33
AI3 filter time
0.00s to 10.00s
0.10s
☆
105
F1.34
HDI Filter time
0.00s to 10.00s
0.00s
☆
106
F1.35
DI terminal valid mode
selection 1
Units digit: DI1
0: high level active
1: low level active
Tens digit: DI2
Hundreds digit: DI3
Thousands digit: DI4
Ten thousands digit: DI5
00000
★
107
F1.36
DI terminal valid mode
selection 2
Units digit: DI6
0: high level active
1: low level active
Tens digit: DI7
Hundreds digit: DI8
Thousands digit: DI9
Ten thousands digit: DI10
00000
★
108
F1.37
DI1 delay time
0.0s to 3600.0s
0.0s
★
109
F1.38
DI2 delay time
0.0s to 3600.0s
0.0s
★
110
F1.39
DI3 delay time
0.0s to 3600.0s
0.0s
★
111
F1.40
Define the input terminal repeat
0:unrepeatable 1:repeatable
0
★
