Powtran PI500A Series User Manual

Chapter 5 Function parameter
42
Chapter 5
161
F4.07
Multipoint V/F frequency point 3
F4.05 to b0.04 (rated motor
frequency)
0.00Hz
★
162
F4.08
Multipoint V/F voltage point 3
0.0% to 100.0%
0.0%
★
163
F4.09
Slip compensation coefficient
0% to 200.0%
0.0%
☆
164
F4.10
Overexcitation gain
0 to 200
80
☆
165
F4.11
Oscillation suppression gain
0 to 100
0
☆
166
F4.12
V/F separation voltage source
0 to 9
0
☆
167
F4.13
V/F separation
voltage
digital setting
0V to rated motor voltage
0V
☆
168
F4.14
V/F separation voltage rise time
0.0s to 1000.0s
0.0s
☆
5-1-7.F5 Group - Vector control parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
169
F5.00
Speed loop ratio G1
1 to 100
30
☆
170
F5.01
Speed loopintegral T1
0.01s to 10.00s
0.50s
☆
171
F5.02
switching frequency 1
0.00 to F5.05
5.00Hz
☆
172
F5.03
Speed loop ratio G2
0 to 100
20
☆
173
F5.04
Speed loop integral T2
0.01s to 10.00s
1.00s
☆
174
F5.05
switching frequency 2
F5.02 to F0.19(max. frequency)
10.00Hz
☆
175
F5.06
Speed loop integral
0: invalid 1: valid
0
☆
176
F5.07
Torque limit upper limit source
0: Function code F5.08 setting
1: AI1
2: AI2
3: Panel potentiometer setting
4: High-speed pulse setting
5: Communication setting
6: Min(AI1, AI2)
7: Max(AI1, AI2)
8: AI3 setting
0
☆
177
F5.08
Upper limit digital setting for torque
0.0% to 200.0%
150.0%
☆
178
F5.09
Vector control differential gain
50% to 200%
150%
☆
179
F5.10
Speed loop filter time constant
0.000s to 0.100s
0.000s
☆
180
F5.11
Vector control overexcitation gain
0 to 200
64
☆
181
F5.12
Excitation regulator proportional
gain
0 to 60000
2000
☆
182
F5.13
Excitation regulator integral gain
0 to 60000
1300
☆
183
F5.14
Torque regulator proportional gain
0 to 60000
2000
☆
184
F5.15
Torque regulator integral gain
0 to 60000
1300
☆
5-1-8.F6 Group - Keyboard and display
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
185
F6.00
STOP/RESET key functions
0: STOP/RES key is enabled only
1
☆
