Powtran PI500A Series User Manual

Chapter 5 Function parameter
41
Chapter 5
141
F3.03
Start frequency
0.00Hz to 10.00Hz
0.00Hz
☆
142
F3.04
Hold time for start frequency
0.0s to 100.0s
0.0s
★
143
F3.05
DC beforehand field current
0% to 100%
0%
★
144
F3.06
DC excitation time beforehand
0.0s to 100.0s
0.0s
★
145
F3.07
Stop mode
0: Deceleration
parking
1: Free
stop
0
☆
146
F3.08
DC Initial frequency
0.00Hz to F0.19 (maximum
frequency)
0.00Hz
☆
147
F3.09
DC Waiting time
0.0s to 100.0s
0.0s
☆
148
F3.10
Stop DC braking current
0% to 100%
0%
☆
149
F3.11
Stop DC braking time
0.0s to 100.0s
0.0s
☆
150
F3.12
Braking utilization rate
0% to 100%
100%
☆
151
F3.13
Ac/deceleration mode
0: Linear acceleration and
deceleration
1:S curve acceleration and
deceleration A
2:S curve acceleration and
deceleration B
0
★
152
F3.14
Proportion of S curve start-section
0.0% to (100.0%to F3.15)
30.0%
★
153
F3.15
Proportion of S curve end-section
0.0% to (100.0% to F3.14)
30.0%
★
5-1-6.F4 Group - V/F control parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
154
F4.00
V/F curve setting
0: linear V/F,Suitable for
ordinary constant torque load.
1: multi-point V/F,Suitable for
dehydrator, centrifuge and other
special loads any V/F
relationship curves can be
obtained by setting parameters
F4.03 to F4.08.
2: square V/F,Suitable for fans,
pumps and centrifugal loads.
3 to 8: V/F relationship curve
between linear V/F and square
V/F.
0
★
155
F4.01
Torque boost
0.0%(Automatic torque boost)
0.1
to 30%
0.0%
★
156
F4.02
Torque boost cut-off frequency
0.00Hz to F0.19(maximum
frequency)
15.00
Hz
★
157
F4.03
MultipointV/F frequency point 1
0.00Hz to F4.05
0.00Hz
★
158
F4.04
Multipoint V/F voltage point 1
0.0% to 100.0%
0.0%
★
159
F4.05
Multipoint V/F frequency point 2
F4.03 to F4.07
0.00Hz
★
160
F4.06
Multipoint V/F voltage point 2
0.0% to 100.0%
0.0%
★
