Powtran PI500A Series User Manual

Chapter 5 Function parameter
40
Chapter 5
7
Anolog AI1
0V~10V(Or 0～20mA)
8
Anolog AI2
0V~10V(or 0~20mA)
9
Anolog AI3
0V～10V
10
Lentgh value
0~Max. setting length
11
The count value
0~Max. count value
12
Coummunication set
0.0%~100.0%
13
Motor speed
0~Max. output frequency correspondent speed
14
Output current
0.0A~100.0A(Inverter power≦55kW) ；
0.0A~1000.0A(Inverter power>55kW)
15
DC bus voltage
0.0V~1000.0V
16
Reserve
Reserve
17
Frequency source main set
0~Max. output frequency
127
F2.09
Maximum output frequency of high-
speed pulse
0.01kHzto 100.00kHz
50.00k
Hz
☆
128
F2.10
SPB switching quantity output delay
time
0.0s to 3600.0s
0.0s
☆
129
F2.11
Relay 1 output delay time
0.0s to 3600.0s
0.0s
☆
130
F2.12
Expansion card DO output delay
time
0.0s to 3600.0s
0.0s
☆
131
F2.13
SPA output delay time
0.0s to 3600.0s
0.0s
☆
132
F2.14
Relay 2 output delay time
0.0s to 3600.0s
0.0s
☆
133
F2.15
DO output terminal active status
selection
Units digit: SPB switching
quantity
0: positive logic
1: anti-logic
Tens digit: Relay 1
Hundreds digit: Hundreds
digit: Undefined
Thousands digit: SPA
Ten thousands digit: Relay 2
00000
☆
134
F2.16
DA1 zero bias coefficient
-100.0% to +100.0%
0.0%
☆
135
F2.17
DA1 gain
-10.00 to +10.00
1.00
☆
136
F2.18
DA2 zero bias coefficient
-100.0% to +100.0%
20.0%
☆
137
F2.19
DA2 gain
-10.00 to +10.00
0.80
☆
5-1-5.F3 Group - Start and stop control group
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
138
F3.00
Start-up mode
0: Direct startup
1: Speed tracking restart
2: Pre-excitation start (AC
asynchronous motor)
0
☆
139
F3.01
Speed tracking mode
0~2: reserve
3: Rotate speed tracking method3
3
★
140
F3.02
Speed tracking value
1 to 100
20
☆
