Powtran PI500A Series User Manual

Chapter 5 Function parameter
44
Chapter 5
201
F6.19
Multifunction
key
definition 2
The same as F6.18
0
☆
202
F6.20
Keypad lock selection
0:RUN, STOP button valid
1:RUN, STOP, keypad encode valid
2: RUN, STOP, UP, DOWN button
valid
3: STOP button valid
0
☆
203
F6.21
QUICK key function
selection
0: no function; 1: Jog running
2: Shift switch display state
3: FWD/RVS switchover
4: Clear-up UP/DOWN setting
5: Free stop
6: running command given in
sequence
1
☆
5-1-9.F7 Auxiliary function group
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
204
F7.00
Jog running frequency
0.00Hz to F0.19(maximum
frequency)
2.00Hz
☆
205
F7.01
Jog acceleration time
0.0s to 6500.0s
20.0s
☆
206
F7.02
Jog deceleration time
0.0s to 6500.0s
20.0s
☆
207
F7.03
Jog priority
0:Invalid 1: Valid
1
☆
208
F7.04
Jump frequency 1
0.00Hz to F0.19 (maximum
frequency)
0.00Hz
☆
209
F7.05
Jump frequency 2
0.00Hz to F0.19(maximum
frequency)
0.00Hz
☆
210
F7.06
Jump frequency range
0.00Hz to F0.19 (maximum
frequency)
0.00Hz
☆
211
F7.07
Jump frequency
availability during
ac/
deceleration
process
0: Invalid 1:
Valid
0
☆
212
F7.08
Acceleration time 2
0.0s to 6500.0s
Depends on
models
☆
213
F7.09
Deceleration time 2
0.0s to 6500.0s
Depends on
models
☆
214
F7.10
Acceleration time 3
0.0s to 6500.0s
Depends on
models
☆
215
F7.11
Deceleration time 3
0.0s to 6500.0s
Depends on
models
☆
216
F7.12
Acceleration time 4
0.0s to 6500.0s
Depends on
models
☆
217
F7.13
Deceleration time 4
0.0s to 6500.0s
Depends on
models
☆
218
F7.14
Switching frequency point
between acceleration time 1
and acceleration time 2
0.00Hz to F0.19 (maximum
frequency)
0.00Hz
☆
219
F7.15
Switching frequency point
0.00Hz to F0.19 (maximum
0.00Hz
☆
