Powtran PI500A Series User Manual

Chapter 5 Function parameter
47
Chapter 5
259
F8.01
Overcurrent stall
protection current
100% to 200%
-
☆
260
F8.02
Motor overload
protection selection
0: Invalid 1: Enable
1
☆
261
F8.03
Motor overload
protection gain
0.20 to 10.00
1.00
☆
262
F8.04
Motor overload pre-
alarm coefficient
50% to 100%
80%
☆
263
F8.05
Over-voltage stall gain
0 to 100
0
☆
264
F8.06
Over-voltage stall
protection voltage /
energy consumption
brake voltage
120% to 150%
130%
☆
265
F8.07
Input phase loss
protection selection
Units digit:Input phase loss protection
selection
0: Invalid 1: Enable
Tens digit:contactor actuation
protection
0: Invalid 1: Enable
11
☆
266
F8.08
Output phase loss
protection selection
0: Invalid 1: Enable
1
☆
267
F8.09
Short to ground
protection
0:Invalid 1: Valid
1
☆
268
F8.10
Number of automatic
fault reset
0 to 32767
0
☆
269
F8.11
Fault DO action
selection during
automatic fault reset
0: OFF
1: ON
0
☆
270
F8.12
Automatic fault reset
interval
0.1s to 100.0s
1.0s
☆
271
F8.13
Over-speed detection
value
0.0 to 50.0% (maximum frequency)
20.0%
☆
272
F8.14
Over-speed detection
time
0.0 to 60.0s
1.0s
☆
273
F8.15
Detection value for too
large speed deviation
0.0 to 50.0% (maximum frequency)
20.0%
☆
274
F8.16
Detection time for too
large speed deviation
0.0 to 60.0s
5.0s
☆
275
F8.17
Fault protection action
selection 1
Units digit: Motor overload (Err.11)
0: Free stop
1: Stop at the selected mode
2: Continue to run
Tens digit: input phase loss (Err.12)
(same as units digit)
Hundred digit: output phase loss
(Err.13) (same as units digit)
Thousand digit: external fault (Err.15)
(same as units digit)
00000
☆
