Powtran PI500A Series User Manual

Chapter 5 Function parameter
53
Chapter 5
374
E1.43
12 stage ac/deceleration time
selection
0 to 3
0
☆
375
E1.44
13 stage running time T13
0.0s(h) to 6500.0s(h)
0.0s(h)
☆
376
E1.45
13 stage ac/deceleration time
selection
0 to 3
0
☆
377
E1.46
14 stage running time T14
0.0s(h) to 6500.0s(h)
0.0s(h)
☆
378
E1.47
14 stage ac/deceleration time
selection
0 to 3
0
☆
379
E1.48
15 stage running time T15
0.0s(h) to 6500.0s(h)
0.0s(h)
☆
380
E1.49
15 stage ac/deceleration time
selection
0 to 3
0
☆
381
E1.50
Simple PLC run-time unit
0: S (seconds) 1: H (hours)
0
☆
382
E1.51
Multi-stage command 0
reference manner
0: Function code E1.00 reference
1:
Analog AI1
reference
2:
Analog AI2 reference
3:
Panel
potentiometer setting
4:
High-speed pulse
setting
5:
PID control setting
6:
Keyboard set frequency (F0.01)
setting
, UP/DOWN can be modified
7. Analog AI3 given
0
☆
5-1-17.E2 Group - PID function
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
383
E2.00
PI D setting source
0: E2.01 setting
1: Analog AI1
reference
2: Analog AI2 reference
3: Panel potentiometer setting
4: High-speed pulse setting
5: Communications reference
6: Multi-stage command reference
0
☆
384
E2.01
PID keyboard reference
0.0% to 100.0%
50.0%
☆
385
E2.02
PID feedback source
0: Analog AI1 reference
1: Analog AI2 reference
2: Panel potentiometer setting
3: AI1-AI2 reference
4: High-speed pulse setting
5: Communications reference
6: AI1+AI2 reference
7: MAX(|AI1|, |AI2|) reference
8: MIN (|AI1|, |AI2|) reference
9: Analog AI3 reference
0
☆
386
E2.03
PID action direction
0:
positive 1: negative
0
☆
387
E2.04
PID setting feedback range
0 to 65535
1000
☆
388
E2.05
PID inversion cutoff frequency
0.00 to F0.19(maximum frequency)
0.00Hz
☆
389
E2.06
PID deviation limit
0.0% to 100.0%
2.0%
☆
