Powtran PI500A Series User Manual

Chapter 5 Function parameter
54
Chapter 5
390
E2.07
PID differential limiting
0.00% to 100.00%
0.10%
☆
391
E2.08
PID reference change time
0.00s to 650.00s
0.00s
☆
392
E2.09
PID feedback filter time
0.00s to 60.00s
0.00s
☆
393
E2.10
PID output filter time
0.00s to 60.00s
0.00s
☆
394
E2.11
PID feedback loss detection
value
0.0%:
not judged feedback loss
0.1% to
100
.0%
0.0%
☆
395
E2.12
PID feedback loss detection
time
0.0s to 20.0s
0.0s
☆
396
E2.13
Proportional gain KP1
0.0 to 200.0
80.0
☆
397
E2.14
Integration time Ti1
0.01s to 10.00s
0.50s
☆
398
E2.15
Differential time Td1
0.00s to 10.000s
0.000s
☆
399
E2.16
Proportional gain KP2
0.0 to 200.0
20.0
☆
400
E2.17
Integration time Ti2
0.01s to 10.00s
2.00s
☆
401
E2.18
Differential time Td2
0.00 to 10.000
0.000s
☆
402
E2.19
PID parameter switching
conditions
0:
no switching
1:
switching via terminals
2:
automatically switching
according to deviation.
0
☆
403
E2.20
PID parameter switching
deviation 1
0.0% to E2.21
20.0%
☆
404
E2.21
PID parameter switching
deviation 2
E2.20 to 100.0%
80.0%
☆
405
E2.22
PID integral properties
Units digit: integral separation
0: Invalid; 1: Valid
Tens digit: whether stop integration
when output reaches limit
0: continue; 1: stop
00
☆
406
E2.23
PID initial value
0.0% to 100.0%
0.0%
☆
407
E2.24
PID initial value hold time
0.00s to 360.00s
0.00s
☆
408
E2.25
Maximum deviation of twice
outputs(forward)
0.00% to 100.00%
1.00%
☆
409
E2.26
Maximum deviation of twice
outputs(backward)
0.00% to 100.00%
1.00%
☆
410
E2.27
Computing status after PID
stop
0: stop without computing
1: stop with computing
1
☆
411
E2.28
reserved
412
E2.29
PID automatic decrease
frequency selection
0:invalid；1:valid
1
☆
413
E2.30
PID stop frequency
0.00Hz~maximum
frequency(F0.19)
25
☆
414
E2.31
PID checking time
0s~3600
s
10
☆
415
E2.32
PID checking times
1~500
20
☆
