Powtran PI500A Series User Manual

Chapter 5 Function parameter
55
Chapter 5
5-1-18.E3 Group – Virtual DI、Virtual DO
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
416
E3.00
Virtual VDI1 terminal function
selection
0 to 50
0
★
417
E3.01
Virtual VDI2 terminal function
selection
0 to 50
0
★
418
E3.02
Virtual VDI3 terminal function
selection
0 to 50
0
★
419
E3.03
Virtual VDI4 terminal function
selection
0 to 50
0
★
420
E3.04
Virtual VDI5 terminal function
selection
0 to 50
0
★
421
E3.05
Virtual VDI terminal status set
Units digit:Virtual VDI1
Tens digit:Virtual VDI2
Hundreds digit:Virtual VDI3
Thousands digit:Virtual VDI4
Tens of thousands:Virtual VDI5
00000
★
422
E3.06
Virtual VDI terminal effective
status set mode
Units digit:Virtual VDI1
Tens digit:Virtual VDI2
Hundreds digit:Virtual VDI3
Thousands digit:Virtual VDI4
Tens of thousands:Virtual VDI5
11111
★
423
E3.07
AI1 terminal as a function
selection of DI
0 to 50
0
★
424
E3.08
AI2 terminal as a function
selection of DI
0 to 50
0
★
425
E3.09
Panel potentiometer as a
function selection of DI
0 to 50
426
E3.10
AI as DI effective mode
selection
Units digit:AI1
0:High level effectively
1:Low level effectively
Tens digit:AI2(0 to 1,same as units
digit)
Hundreds digit: Panel
potentiometer(0 to 1,same as units
digit)
000
★
427
E3.11
Virtual VDO1 output function
selection
0 to 40
0
☆
428
E3.12
Virtual VDO2 output function
0 to 40
0
☆
429
E3.13
Virtual VDO3 output function
0 to 40
0
☆
430
E3.14
Virtual VDO4 output function
0 to 40
0
☆
431
E3.15
Virtual VDO5 output function
0 to 40
0
☆
432
E3.16
VDO output terminal effective
status selection
Units digit:VDO1
0:Positive logic
1:Negative logic
Tens digit: VDO2(0 to 1,same as
00000
☆
