Powtran PI500A Series User Manual

Chapter 5 Function parameter
56
Chapter 5
above)
Hundreds digit:VDO3(0 to 1,same
as above)
Thousands digit:VDO4(0 to 1,same
as above)
Tens of thousands digit:VDO5(0 to
1,same as above)
433
E3.17
VDO1 output delay time
0.0s to 3600.0s
0.0s
☆
434
E3.18
VDO2 output delay time
0.0s to 3600.0s
0.0s
☆
435
E3.19
VDO3 output delay time
0.0s to 3600.0s
0.0s
☆
436
E3.20
VDO4 output delay time
0.0s to 3600.0s
0.0s
☆
437
E3.21
VDO5 output delay time
0.0s to 3600.0s
0.0s
☆
5-1-19.b0 Group -Motor parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan-
ge
438
b0.00
Motor type selection
0: general asynchronous motor
1: asynchronous inverter motor
2: permanent magnet synchronous
motor
0
★
439
b0.01
Rated power
0.1kW to 1000.0kW
Depends on
models
★
440
b0.02
Rated voltage
1V to 2000V
Depends on
models
★
441
b0.03
Rated current
0.01A to 655.35A (inverter power ≦
55kW)
0.1A to 6553.5A (inverter rate> 55kW)
Depends on
models
★
442
b0.04
Rated frequency
0.01Hz to F0.19 (maximum frequency)
Depends on
models
★
443
b0.05
Rated speed
1rpm to 36000rpm
Depends on
models
★
444
b0.06
Asynchronous motor
stator resistance
0.001Ω to 65.535Ω (inverter power <=
55kW)
0.0001Ω to 6.5535Ω (inverter power>
55kW)
Motor
parameters
★
445
b0.07
Asynchronous motor
rotor resistance
0.001Ω to 65.535Ω (inverter power <=
55kW)
0.0001Ω to 6.5535Ω (inverter power>
55kW)
Motor
parameters
★
446
b0.08
Asynchronous motor
leakage inductance
0.01mH to 655.35mH (inverter power
<= 55kW)
0.001mH to 65.535mH (inverter
power> 55kW)
Motor
parameters
★
447
b0.09
Asynchronous motor
mutUal inductance
0.1mH to 6553.5mH (inverter power
<= 55kW)
0.01mH to 655.35mH (inverter power>
55kW)
Motor
parameters
★
