Powtran PI500A Series User Manual

Chapter 5 Function parameter
57
Chapter 5
448
b0.10
Asynchronous motor
no-load current
0.01A to b0.03 (inverter power <=
55kW)
0.1A to b0.03 (inverter power> 55kW)
Motor
parameters
★
449
b0.11
Synchronous motor
stator resistance
0.001Ω to 65.535Ω (inverter power <=
55kW)
0.0001Ω to 6.5535Ω (inverter power>
55kW)
-
★
450
b0.12
Synchronous D-axis
inductance
0.01mH to 655.35mH (inverter power
<= 55kW)
0.001mH to 65.535mH (inverter
power> 55kW)
-
★
451
b0.13
Synchronous Q-axis
inductance
0.01mH to 655.35mH (inverter power
<= 55kW)
0.001mH to 65.535mH (inverter
power> 55kW)
-
★
452
b0.14
Synchronous motor
back-EMF
0.1V to 6553.5V
-
★
453
b0.15
to
b0.26
Reserve
454
b0.27
Motor parameter auto
tunning
0: no operation
1: asynchronous motor parameters still
auto tunning
2: asynchronous motor parameters
comprehensive auto tunning
11: synchronous motor parameters still
auto tunning
12: synchronous motor parameters
comprehensive auto tunning
0
★
455
b0.28
Encoder type
0: ABZ incremental encoder
1: UVW incremental encoder
2: Rotational transformer
3: Sine and cosine encoder
4: Wire-saving UVW encoder
0
★
456
b0.29
Encoder every turn
pulse number
1 to 65535
2500
★
457
b0.30
Encoder installation
angle
0.00 to 359.90
0.00
★
458
b0.31
ABZ incremental
encoder AB phase
sequence
0: forward 1: reverse
0
★
459
b0.32
UVW encoder offset
angle
0.00 to 359.90
0 . 0
★
460
b0.33
UVW encoder UVW
phase sequence
0: forward 1: reverse
0
★
461
b0.34
Speed feedback PG
disconnection
detection time
0.0s: OFF
0.1s to 10.0s
0.0s
★
462
b0.35
Pole-pairs of rotary
1 to 65535
1
★
