2
Setting up the Ether232Plus
2.1 Installing the Hardware
CAUTION: Use the 9V power adapter supplied by Precidia or an
adapter conforming exactly to the specifications in Appendix E: Pinouts
and Power Supply. Use of alternate power adapters can result in hard-
ware damage and will render the warranty null and void!
1 Connect the power adapter to the POWER port of the unit.
2 Connect the Ethernet cable to the ETHERNET port of the unit.
3 Connect the null modem cable to the COM port of the unit.
4 Plug the power adapter into a power outlet.
5 Connect the null modem cable to one of the COM ports on your PC.
6 Follow Section 2.2 to set up your terminal software and access the Configuration
screen.
7 Configure the unit (Sections 3 through 6).
N
OTE
: You must set the Remote Password locally before you can configure the
Ether232Plus remotely.
After Configuration
1 Disconnect the null modem cable from the COM port of your PC.
2 Connect your serial device to the COM port of the Ether232Plus using the appropri-
ate cable. (See Section 1.4, Hardware Requirements‚ on page 5.)
!
