02-CML000057 Precidia Technologies Inc. 21
4
Configuring the Serial Port
Settings
The Serial Port Settings sub-menu allows you to choose the protocol for communi-
cating with the remote server.
To configure or change the Serial Port Settings choose
Serial Port
from the Device
Settings
menu.
The Serial Port Settings sub-menu appears on the right side of the Configuration
screen, an example of which is shown below.
N
OTE
: Once you choose a protocol, different options appear in the sub-menu. Set the
Protocol option first.
N
OTE
: Remember to save your changes by typing "*" to exit configuration!
,-----------------------------------------------------------------------------.
| Precidia Ether232Plus Configuration v4.04.00 |
|-----------------------------------------------------------------------------|
| Device Settings: | Serial Port Settings: |
| | |
| 1) Ethernet: 0.0.0.0 | A) Protocol: Transparent (tcp) |
| | B) Port Setting: 9600 bps 8N1 [hw] |
| 2) Serial Port: Transparent | C) Port Mode: RS-232 |
| | D) Connection Control: Automatic |
| | |
| | E) Local Port: 9998 |
| | F) Remote IP: 0.0.0.0 |
| | G) Remote Port: 0 |
| | H) Fallback IP: 255.255.255.255 |
| | I) Fallback Port: 0 |
| | |
| *) Save Current Configuration | J) Packet Prefix: none |
| -) Exit Configuration (no save) | K) Max Inter-Char Delay: 0 |
| $) Security Settings | L) Preferred Packet Size: 0 |
| #) System Settings | |
| ?) Refresh this Screen | M) Initial String: (not set) |
`-----------------------------------------------------------------------------'
Change which option?
Example of the Serial Port Settings Sub-menu
