Ether232Plus User Guide Appendix E: Pinouts and Power Supply
02-CML000027 Precidia Technologies Inc. E-5
Power Supply
Customers in North America are supplied with an AC power adapter conforming to
the specifications below. Customers in other parts of the world should obtain a power
supply that meets these requirements.
Output Voltage: 9 VDC @ 500 mA
Polarity: Center Pin Negative (-) or
Positive (+)
Inside Diameter: 2.1 mm
Outside Diameter: 5.5 mm
Barrel Length: 9.5 mm
Class 2 Transformer
-
+
+
-
2.1
mm
5.5 mm
9.5 mm
Center Polarity: Negative (-)
2.1 mm
5.5 mm
9.5 mm
Center Polarity: Pos (+) or Neg (-)
