Precidia ipocket232 - 4 Configuring the Serial Port Settings

21 iPocket232 Technologies Inc. 23-CML000293
4 Configuring the Serial Port
Settings
The Serial Port Settings sub-menu allows you to choose the protocol for communicating
with the remote server.
To configure or change the Serial Port Settings choose Serial Port from the Device
Settings menu.
The Serial Port Settings sub-menu appears on the right side of the Configuration screen,
an example of which is shown below.
N
OTE
: Once you choose a protocol, different options appear in the sub-menu. Set the
Protocol option first.
,-----------------------------------------------------------------------------.
| iPocket232 iPocket232 Configuration v4.03.00 |
|-----------------------------------------------------------------------------|
| Device Settings: | Serial Port Settings: |
| | |
| 1) Ethernet: 0.0.0.0 | A) Protocol: Transparent (tcp) |
| | B) Port Setting: 300 bps 8N1 [no] |
| 2) Serial Port: Transparent | C) Connection Control: Automatic |
| | |
| | D) Local Port: 0 |
| | E) Remote IP: 0.0.0.0 |
| | F) Remote Port: 0 |
| | G) Fallback IP: 0.0.0.0 |
| | H) Fallback Port: 0 |
| | |
| *) Save Current Configuration | I) Packet Prefix: none |
| -) Exit Configuration (no save) | J) Max Inter-Char Delay: 0 |
| $) Security Settings | K) Preferred Packet Size: 0 |
| #) System Settings | |
| ?) Refresh this Screen | L) Initial String: (not set) | `-----------
------------------------------------------------------------------'
Change which option?
Example of the Serial Port Settings Sub-menu
N
OTE
: Remember to save your changes by typing "*" to exit configuration!
