7 Accessing System Information iPocket232 User Guide
23-CML000293 iPocket232 Inc. 60
Table 7.2: Network Routing Parameters
Total number of packets sent by the unit since the last reset.
Total number of error packets received by the unit since the last
reset.
7.2 System Log
The System Log, an example of which is shown below, logs transaction data and system
information. Connection attempts and failures, and remote and console access attempts
are logged.
iPocket232 Log:
===== iPocket232 Started =====
00000 days 00:00:00 Port #1: Listening for connections on tcp port 9999...
00000 days 09:07:22 Port #1: Incoming connection on tcp port 9999 from 192.168.1.2:2569
00000 days 09:07:22 Port #1: Connection was established with 192.168.1.2:2569
00000 days 09:07:37 Port #1: Connection closed by remote host at 192.168.1.2:2569
00000 days 09:07:37 Port #1: Connection closed by us to host at 192.168.1.2:2569
00000 days 22:09:02 Port #1: Incoming connection on tcp port 9999 from 192.168.1.2:2664
00000 days 22:09:02 Port #1: Connection was established with 192.168.1.2:2664
00000 days 22:10:32 Port #1: Connection closed by remote host at 192.168.1.2:2664 00000 days
22:10:32 Port #1: Connection closed by us to host at 192.168.1.2:2664
===== iPocket232 Started =====
00000 days 00:00:00 Port #1: Connection attempt to 192.168.1.2:999...
00000 days 00:00:00 Port #1: Connection with 192.168.1.2:999 stopped due to connection
control
00000 days 00:00:01 Port #1: Connection attempt to 192.168.1.2:999...
00000 days 00:00:01 Port #1: Connection was established with 192.168.1.2:9999 00000 days
23:01:49 current system time Please hit <return>:
Example of the System Log Page
Accessing the System Log
To access the System Log through a browser:
1 Ensure the Web Server in the Security Settings sub-menu is enabled and you have the
Access Userid and Access Password, if set.
2 Open your browser.
3 Type http://IPaddressOfUnit/log.html in the address bar.
To access the System Log in configuration mode:
