4 Configuring the Serial Port Settings iPocket232 User Guide
23-CML000293 iPocket232 Inc. 32
1 Choose Serial Port from the Device Settings menu.
2 Choose Fallback Port from the Serial Port Settings sub-menu.
You are prompted to enter the port number on the fallback system.
3 Type the fallback port address and press Enter.
4.10 Terminators (Terminated Protocol Only)
If you select Terminated in the Protocol setting, you are able to configure up to six
terminators in the Serial Port Settings sub-menu, as shown below.
,-----------------------------------------------------------------------------.
| iPocket232 iPocket232 Configuration v4.03.00 |
|-----------------------------------------------------------------------------|
| Device Settings: | Serial Port Settings: |
| | |
| 1) Ethernet: 0.0.0.0 | A) Protocol: Terminated (tcp) |
| | B) Port Setting: 300 bps 8N1 [no] |
| 2) Serial Port: Terminated | C) Connection Control: Automatic |
| | |
| | D) Local Port: 0 |
| | E) Remote IP: 0.0.0.0 |
| | F) Remote Port: 0 |
| | G) Fallback IP: 0.0.0.0 |
| | H) Fallback Port: 0 |
| | |
| | I) Terminator #1: 000 < > : 000 |
| *) Save Current Configuration | J) Terminator #2: 000 < > : 000 |
| -) Exit Configuration (no save) | K) Terminator #3: 000 < > : 000 |
| $) Security Settings | L) Terminator #4: 000 < > : 000 |
| #) System Settings | M) Terminator #5: 000 < > : 000 |
| ?) Refresh this Screen | N) Terminator #6: 000 < > : 000 | `-----------
------------------------------------------------------------------'
Change which option?
Setting the Terminators
The iPocket232 continues to capture data from the serial port into the receive buffer until
any one of six specific terminators is identified. Once this character is marked, the
iPocket232 continues to capture a configurable number of characters (tail bytes), then
terminates the frame and transmits it to the host.
Terminators must be specified in their ASCII decimal form. For example, Carriage
Return is entered as 13. The most common terminators are listed in Table 4.6 .
N
OTE
: To use zero (null) as a terminator, you must set it as Terminator #1. Any zeroes
after the first terminator are ignored.
To configure or change the terminating characters:
