5 Configuring the Security Settings iPocket232 User Guide
23-CML000293 iPocket232 Inc. 45
5 Type the letter that corresponds to the desired mode and press Enter.
The Secure IP Association sub-menu appears, with new options, as shown below.
,-----------------------------------------------------------------------------.
| iPocket232 iPocket232 Configuration v4.03.00 |
|-----------------------------------------------------------------------------|
| Device Settings: | Secure IP Association #1: |
| | |
| 1) Ethernet: 0.0.0.0 | A) Protocol: 3DES-MD5-96 |
| | B) Secure Address: (public) |
| 2) Serial Port: disabled | C) SPI: 00000000 |
| | |
| | D) Network Address: 0.0.0.0 |
| | E) Network Mask: 0.0.0.0 |
| | F) Network Gateway: 0.0.0.0 |
| | |
| | Encode/Authenticate Keys: |
| | G) Encode (Pt1): 0000000000000000 |
| *) Save Current Configuration | H) Encode (Pt2): 0000000000000000 |
| -) Exit Configuration (no save) | I) Encode (Pt3): 0000000000000000 |
| $) Security Settings | |
| #) System Settings | J) Auth (Pt1): 0000000000000000 |
| ?) Refresh this Screen | K) Auth (Pt2): 0000000000000000 |
`-----------------------------------------------------------------------------'
Change which option?
Secure IP Association Sub-menu
6 Configure the Secure IP settings as described in the following sections.
Secure Address
Secure Address is an optional parameter to configure a “private” IP address for the iPocket232 on the
network. This IP address can be the same or different from the IP address configured in the Ethernet
Settings.
If you leave the Secure address set to zero (0.0.0.0) it will display as “public” in the menu and
automatically default to the configured or dynamic IP Address of the unit.
To enter or change the Secure IP address:
1 Choose Secure Address from the Secure IP Association sub-menu. You are prompted to
enter the secure IP address of this device.
2 Type the secure IP address at the prompt (in the format xxx.xxx.xxx.xxx) and press Enter.
