4 Configuring the Serial Port Settings iPocket232 User Guide
23-CML000293 iPocket232 Inc. 28
Table 4.4: Connection Control Options
Links the protocol connection to the status of the network
(Ethernet). Attempts to keep the connection permanently open.
Uses the DTR/DSR lines to open and close connections. In tcp-
client mode, the iPocket232 establishes an IP connection to the
remote host when DSR is asserted and terminates a connection
when DSR is negated.
In tcp-server mode, the iPocket232 asserts DTR when there is a
valid incoming connection attempt and accepts the connection as
soon as DSR is asserted.
In tcp(tunnel) mode the iPocket232 both accepts and establishes
connections to the host.
Uses the RTS/CTS lines to open and close connections. In tcp-
client or tcp(tunnel) mode, the iPocket232 establishes an IP
connection to the remote host when CTS is asserted and
terminates a connection when CTS is negated.
In tcp-server or tcp(tunnel) mode, the iPocket232 asserts
RTS when there is a valid incoming connection attempt and
accepts the connection if CTS is currently asserted.
Enables the iPocket232 to act as modem to a device connected to
its serial port. The iPocket232 processes a superset of the standard
Hayes command set, including the ability to answer, dial, and
originate a connection. FTP and HTTP are supported with
extended AT commands.
For implementation notes and a description of supported
commands, see Appendix F: Modem Connection Control.
To set or change the Connection Control:
1 Choose Serial Port from the Device Settings menu.
2 Choose Connection Control from the Serial Port Settings sub-menu. You are prompted to enter a
connection control type, as shown below.
A. Automatic B. Net-Linked C. DTR/DSR Control D. RTS/CTS Control
E. Modem
Enter connection control type (letter):
Choosing the Connection Control
