4. Continue to loosen the Take-up roller tension bolts enough to allow the freedom of
movement required to lift the Take-up roller from the mounting brackets. Lift the Take-
up roller while removing from the inside of the running belt. Make sure the Take-up roller
does not drag across the deck surface.
CAUTION:Make sure the Take-up roller does not drag across the deck surface
while removing causing damage to the deck surface.
Installation Instructions
1. Insert the Take-up roller through the running belt so that the roller shaft end with the
hole and slot inserts is on the left side and the end with the flat sided roller shaft is on the
right.
CAUTION:Make sure the Take-up roller does not drag across the deck surface
while inserting through the running belt causing damage to the deck surface.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 137
6 Replacement Procedures
Take-up Roller Replacement
