10. Remove the tension gauge. Then hand turn the crank to break-in the belt. Stop the
belt, place the tension gauge onto the belt and remeasure the belt tension. Make sure
the belt tension remains in spec 70 - 76 lbs (31.8 - 34.5 kgs). Readjust the tension if
out-of-spec.
Belt Tracking Adjustment
11. Verify the belt tracking:
Note:The drive belt tracking does not need to remain perfectly centered on the pul-
ley. The belt is correctly tracking when the belt edges do not rub against either the
left or right flywheel pulley rims during use.
Note:Always use the LEFT belt tension adjustment bolt to make belt tracking
adjustments.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 32
4 Adjustment Procedures
Drive Belt Tension and Tracking Adjustment
