Use a finger to gently pry both fluidic coupling covers off in order to inspect the ink tube

connections underneath.

Picture of Ink Tubing Connections

Tubing into Fluidic

Couplings

Peristaltic

Pump

Pinch Valve and

Vents (x5)

Picture of Rear Ink Tubing Detail

Ink Tubing

Buffer Box

Pump Motor

Peristaltic (ink) Pump

Pinch Valve and

Vents (x5)
