Pro-tools MTRX II - Example System Configurations

Chapter 4: Pro Tools | MTRX II Front and Back Panels
20
Example System Configurations
10 AIN/OUT 2 + 23 AIN/OUT 2 –
11 GND 24 AIN/OUT 1 +
12 AIN/OUT 1 – 25 GND
13 N.C.
Pin no Func. Pin no Func.
