562200-000, Issue 1.2, December 2015
18 of 62
7.2 Operation within the Safe Working Load
With the Lifting Mode active, the current lifting point radius and the
maximum safe working load for that radius are shown.
7.3 Approach to Overload
With the Lifting Mode active, if the load is between 95% and 104% of
the maximum safe working load the system will warn the machine is
close to the lifting capacity at the current height and radius. The system
indicates an approach to overload condition via an internal alarm in conjunction with vis-
ual indicators on the display - no motion is cut.
In the event of an approach to overload or an overload condition, the lifting
point should only be moved in a direction that increases the safe working
load. See section 4 for further information.
If the load is greater than 95% of the
maximum safe working load.
The load capacity indicator will be
amber
The amber LED will be lit
The internal alarm will sound
The message shown here will be
displayed.
If the load is less than 95% of the
maximum safe working load
The load capacity indicator will be
green
The green LED will be lit
