562200-000, Issue 1.2, December 2015
43 of 62
8.4 Low Limits
8.4.1 Low Limit Menu
A low limit can be set by entering a known height on the keypad
or by manually moving the machine to the desired limit.
Using the Low Limits Menu, the low limit can be switched ON and OFF, a low limit can be
set to a known value, or the low limit can be set to the current lowest point.
See sections 8.4.2 to enter a known low and section 8.4.3 for setting the limit by moving
the machine.
Once a limit is set, the internal alarm will sound and the RED LED
will light if the equipment exceeds the current limit. Always check
that the current limit activates at the set point. The restriction cannot be de-
activated if in the alarm state. Observe the operational limitations given in
section 4.
Exit to previous menu
Set low limit using cur-
rent lowest of equip-
ment
Turns monitoring
ON and OFF
Enter a value
Current lowest point. Only displayed if
a Low limit is set.
To Next Page
