562200-000, Issue 1.2, December 2015
48 of 62
9 System Messages
9.1 On Screen Messages
*The approach limit is configurable at point of calibration, check system operation before
commencing work.
PME continuously monitors the presence and condition of the safety controller and sen-
sors. If the safety controller or any sensor fails an error message box will appear at the
bottom of the display. In the event of a failure, the cab mounted beacon (if fitted) will indi-
cate that the system is NOT active, the display red LED will flash and the internal and ex-
ternal alarms will sound.
Close to max height
Highest point of equipment within *0.5m of set limit
Max height reached
Equipment has reached set limit
Close to max radius
Furthest point of equipment within *0.5m of set limit
Max radius reached
Equipment has reached set limit
Close to min radius
Nearest point of equipment within *0.5m of set limit
Min radius reached
Equipment has reached set limit
Close to min height
Lowest point of equipment within *0.5m of set limit
Min height reached
Equipment has reached set limit
Close to SWL
95 percent of the maximum safe working load
Overload
105 percent of the maximum safe working load
Hydraulic Limit
Pressure in the lift rams is in excess of 87% of main
relief valve pressure
In Override
Override has been activated (Soft or master Key)
