562200-000, Issue 1.2, December 2015
29 of 62
8.1.2 Height Limit Setting - Known Height
A known limit can be entered into the display. This is
the vertical height from the ground or base of the ma-
chine:
Press the ’Enter a value’ button
Use the UP and DOWN arrows to increase and decrease the highlighted number. Use
the LEFT and RIGHT arrows to move the highlighter to the left and to the right.
Exit to previous menu
Once a limit is set, the internal alarm will sound and the RED LED
will light if the equipment exceeds the current limit. Always check
that the current limit activates at the set point. The restriction cannot be de-
activated if in the alarm state. Observe the operational limitations given in
section 4.
Enter a value
Decreases highlighted
digit
Moves highlighter to
right
Increases highlighted
digit
Moves highlighter to
left/ Hold to delete digit
Accept displayed value
Cancel without change
To Next Page
