562200-000, Issue 1.2, December 2015
25 of 62
7.11 Lifting Mode - Non Lifting Mode
When the machine is not being used for lifting operations it can be put into
‘Non Lifting Mode’ available from the Top Menu screen.
When in Non Lifting Mode, the system still monitors all machine activity and
safety status but will NOT warn of overload conditions. In this mode, the bea-
con (if fitted) will be off indicating that the Lifting Mode functionality is NOT ac-
tive. Lifting mode cannot be activated if the LOH value exceeds a predefined weight. En-
velope Limit monitoring will remain active if any
limit has been set.
Lifting mode cannot be activated if the LOH value exceeds the
predefined weight, this value defaults to 100kg.
RCI / RCC
ON: when operating with an active limit the indicator will not have a
painted on cross on it.
OFF: when operating without limit the indicator will have a cross painted
on it.
Lifting Mode OFF
Lifting Mode ON
Note Lift Mode button
is not accessible
When in Non Lifting Mode, the screen states NON-LIFTING MODE on the
hazard warning tape and a red cross appears in the RCI RCC indicator - lift-
ing operations should not be attempted in this state. The beacon (if fitted) will
be off.
