4 Assembly and installation
IMPORTANT
• The DMT is fully resistant to normal environments control
rooms.
• The DMT must not be placed where it can come into
contact with rain or direct sunlight!
Use a protective housing or weatherproof cover if in use
out of doors.
4.1 Assembly (mechanical)
The DMT can be wall, pipe or panel mounted (not for PROFIBUS
®
-DMT).
4.1.1 Wall mounting
Mounting materials (included in delivery):
1 x wall/pipe bracket
2 x 5x45 mm round headed screws
2 x 5.3 washers
2 x wall plugs Ø 8 mm, plastic
1 x rubber insert
1 x locking screw (PT)
Wall mounting, please follow the steps below:
왘 Remove wall/pipe bracket from DMT:
pull the two snap fasteners outwards and push upwards (fig. 1, ➀).
Swing the wall/pipe bracket away from the DMT and pull downwards
(fig. 1, ➁).
왘 Mark two drill holes diagonally opposite one another using the mounting
bracket as a template.
왘 Drill the holes: Ø 8 mm, depth = 50 mm.
왘 Screw the wall/pipe bracket in place inserting the washers (fig. 2).
왘 If the DMT is also to be secured with a screw, pierce the screw hole in the
back of the housing (housing must be open) and attach a rubber insert
(fig. 2, ➀) to the bracket.
왘 Hang the DMT onto the top of the bracket (fig. 3, ➀) and push down
gently against the bracket (fig. 3, ➁), then push upwards until you hear
a click (fig. 3, ➂).
왘 Tighten the locking screw to secure more firmly (housing is open).
