ProMinent
®
Page 13
Panel mounting, please follow the steps below:
왘 Decide on the exact position of the DMT on the panel using the drill
template.
왘 Centre punch the holes for the screws and cut-out through the drilling
template.
왘 Drill the four screw holes with a Ø 3.5 mm diameter drill bit.
왘 Punch out the cut-out or drill the four inner holes using an Ø 8 mm
diameter drill bit and pierce out the cut-out with a keyhole saw.
CAUTION
Sharp edges can cause injury.
왘 File off cut edges.
왘 Insert the profile seal into the groove provided on the DMT.
왘 Place the DMT onto the cut-out and screw in place.
IMPORTANT
Check that the seal is located correctly.
IP 54 is only achieved when assembly has been carried out
correctly.
4.2 Installation (electrical)
IMPORTANT
• Installation must be carried out by specially trained
personnel.
• Installation can only be carried out after assembly has been
completed.
• The device must be connected to a protective low voltage
in accordance with EN 60335-1.
• Observe the relevant technical data in chapter 12
throughout installation procedures.
• The current loop must be disconnected from the power
supply during installation.
• The DMT signal cable must not be laid next to leads subject
to high levels of interference. Can lead to malfunction of
DMT.
• The hinge between the front and back sections of the
housing is not particularly strong. When working on the
front section it should be held securely in place.
Assembly and installation
BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr13
