4.1.2 Pipe mounting
Mounting materials (included in delivery):
1 x wall/pipe bracket
2 x cable ties
1 x sealing cap
1 x locking screw (PT)
Can be mounted onto pipes of diameters from 25 mm to 60 mm.
Assembly and installation
