ProMinent
®
Page 19
6.2 Key functions
The key are used to alter the DMT settings and have the following
functions:
In the permanent display / In the menu options
in the info display
Change key Toggles between permanent Scrolls through values of the
display and info display current menu option
modes
Back key Exits info display mode and Exits to info display without
returns to permanent display saving changes to values
mode
Enter key Accesses menu option Saves changes to values in
(from an info display) current menu option and
accesses the next info
display or another menu
option
CAL key Opens the calibration menu Activates calibration in
(from permanent display) calibration menu (pH only)
Down key Alters brightness of the Changes a value
LC display
Up key (in permanent display mode)
6.3 Operating menu, schematic
The operating menu comprises:
• the permanent display
• the calibration menu
• the info displays (info level)
for the display of pre-set parameters resp. general settings
• menu options (settings level)
for altering parameters resp. general settings
Function description
BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr19
