ProMinent
®
Page 22
DMT settings
7 DMT settings
NOTE
• Settings need only be changed if your process
requirements differ from factory general settings.
• If your DMT does not display the required settings option,
check the general settings of your device as described in
chapter 7.1.7.
Menu overview table
pH probe parameters Zero point, slope and probe
resistance
Redox probe test Compare with buffer Probe resistance
Parameter Detection means:
Temperature • sensor
measurement • manual (enter value)
Unit of measurement
• °C
• °F
Parameter Value:
Output current •
proportional measured variable:
measured variable at 4 mA
measured variable at 20 mA
• manual (enter value)
General settings Measured variable: Settings configuration Access
• pH code
• ORP (redox)
• temperature
Permanent display Calibration of pH probe Zero point and slope
= Request access code
(if activated by the user)
BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr22
