ProMinent gamma/ X User Manual

1st level 2nd 3rd 4th 5th xth
Relay 2 Relay type Inactive
Error
Warning
Warning + error
Pump active
Metering volume
Stroke rate
Metering / Batch
Bleed valve
External
Polarity normally-open (NO)
normally-closed
(NC)
Analogue output 0..20 mA
4..20 mA
Strokes / hour
Capacity at 20 mA
Flow control Flow Control Tolerance / strokes ...
Activation ...
if auxiliary ...
Diaphragm rupture Inactive
Warning
Error
Pause Input normally-open (NO)
normally-closed
(NC)
Level Warning normally-open (NO)
normally-closed
(NC)
Level Error normally-open (NO)
normally-closed
(NC)
Bleed valve Off
Periodic Bleed cycle Bleed metering
time
...
Air lock Bleed metering
time
both Bleed cycle Bleed metering
time
...
Priming time 0 … 60 s
Set time Time Set hh.mm.ss
Auto. summer time
Summer time
begins in
February
March
April
Sunday the 1st, 2nd, 3rd, 4th,
5th
Operating Menu of gamma/ X, Entire Unit
133

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
