Auxiliary displays in the continuous displayAuxiliary displays in the continuous display
Mode "Manual"
Mode "Batch" with
transfer factor 5
Mode "Contact""Contact" with
transfer factor 5
Mode "Analogue"
slow
1 1
2
L
16:12:21
2015 - 03 - 27
16:12:21
2015 - 03 - 27
16:12:21
2015 - 03 - 27
16:12:21
2015 - 03 - 27
slow slow slow
Auxiliary display
Stroke rate
Capacity Factor Stroke length Signal current (at the input) Dosing mode Pressure display Time Total number of strokes Remaining litres Date Remaining strokes
1 = only with "Storage tank" function extension 2 = only with current output
Continuous Displays and Secondary Displays
136

ProMinent gamma/ X Specifications

General

Protection class	IP65
Max. Pressure	25 bar
Power supply	100-230 V, 50/60 Hz
Material of pump head	PVDF, Stainless steel
Temperature range	-10 °C to +45 °C
Type	Diaphragm dosing pump
Stroke length	Adjustable
Stroke frequency	max. 180 strokes/min
Materials in contact with the medium	PVDF, PTFE, stainless steel
Control	Manual, external control via contacts or 0/4-20 mA signal
Control Options	External, potential-free contacts, 0/4-20 mA
Dosing Accuracy	±2%
